Asoni H.264 Vandal Dome IP Camera with 3-Axis feature
Tremendously enhance the installation flexibility to fit various environments
|
Following its dedication to innovation and products line's upgrade, Asoni has taken a new step forward to provide the IP surveillance market with 3-axis vandal dome H-264 IP cameras. CAM615, CAM619M and CAM619MIR are supplied with optional video resolution NTSC and PAL, provide triple streaming in H-264, MPEG4, and MJPEG and support SD card for event recording.
|
 |
| 3-Axis feature is fully available for the newest released CAM615 and optional for CAM619M and CAM619MIR. All these cameras are IP-66 waterproof standard. 3-axis mechanical design enables a flexible installation of these dome cameras. The adjustment angle allows these cameras to pan at 360°, tilt at 75° and rotate at 360° |
|
CAM615 is a CCD H-264 network camera which built-in WDR (Wide Dynamic Range) and also DNR (Digital Noise Reduction). CAM615 is also equipped with IR function for a distance up to 12 meters. The day/night monitoring is possible with built-in mechanism IR cut filter feature. |
 |
 |
|
CAM619M & CAM619MIR are booth 2 megapixels IP cameras with CMOS image sensor. Likewise CAM615, CAM619MIR is also supplied with an IR for a distance up to 12 meters. It allows a day/night monitoring with built-in mechanism IR cut filter feature.
A complete SDK (software Development Kit) is provided for software integration upon demand.
Data Sheet:
CAM615,
CAM619M and
CAM619MIR
For further information, please contact us at
marketing@a-soni.com |
|
 |
| -- H.264 / MJPEG / MPEG4 (for 3GPP) Triple compression |
-- Resolution up to 1600 x 1200 (CAM619M, CAM619MIR) |
| -- H.264 / MJPEG / MPEG4 (for 3GPP) Triple streaming |
-- Built-in WDR for strong light (CAM615) |
| -- 1 digital alarm in / 1 Relay out |
-- Built-in DNR for reducing noise (CAM615) |
| -- 1 analog video output |
-- IR distance up to 12 meters (CAM615, CAM619MIR) |
| -- Support SD card for event recording |
-- 3GPP for monitoring via 3G mobile phone |
| -- 2 way audio ( 1 Mic in / 1 Line out ) |
-- Water proof IP66 |
|
 |
 |
 |
 |
 |
