| Video Type |
NTSC |
PAL |
| Video Input |
4 CH Input / 1V p-p / 75 Ohm / BNC |
| Audio Input |
1 CH Input / RCA |
| Video Output |
1 CH Monitor Output/ BNC |
| Audio Output |
1 CH Output / RCA |
| VGA Output |
D-SUB 15Pin VGA |
| Display Frame |
120 fields/s (4x30 fields/s) |
100 fields/s (4x25 fields/s) |
| Recording Frame Rate (QUAD) |
Max. 30 fps |
Max. 25 fps |
| Recording Frame Rate (Each) |
Max. 7.5 fps (30 fps/4) |
Max. 6.25 fps (25 fps/4) |
| Recording Mode |
Continuous/ Motion/ Programmed |
| Display Resolution |
720 x 480 |
720 x 576 |
| Recording Resolution |
640 x 224 |
640 x 272 |
| Data Size |
Low |
12KB / Frame |
Normal |
15KB / Frame |
High |
20KB / Frame |
| Compression Algorithm |
Modified M-JPEG |
| OS |
Embedded RTOS |
| HDD Type |
IDE HDD x 1 |
| Backup |
USB |
| Search Mode |
Full screen, search by Time/ Date/ Event |
| Motion Detection |
Yes |
| Video Loss Detection |
Yes |
| Sequence Switch |
Yes |
| Buzzer Output |
Yes |
| Brightness Adjust |
Yes |
| Contrast Adjust |
Yes |
| USB Output |
Yes |
| VGA Output |
Yes |
| LAN Output |
Yes (Optional) |
| System Monitor |
Power recover auto restore record mode |
| Power Supply |
DC 12V / 4A (AC100V~240V, 50/60HZ) |
| Dimensions |
22(W) x 28.8(D) x 4.8(H) cm |
| Weight |
1.5Kg (Without Hard Disk) |
