| Video Input |
16, BNC |
| Audio Input |
16, RCA |
| Monitor Output |
1, BNC |
| VGA Output |
1, D-SUB |
| Sensor Input |
4 (Optional) |
| Relay Output |
4, AC:125A/12A, 250V/7A; DC:30V/7A |
| Hard Drive |
2 IDE Hard Drive Support |
| Backup |
1 DVD-RW & USB Ports for Memory Stick |
| Network Connector |
RJ45 (10/100Mbps Ethernet) |
| Power Input |
115VAC/4A ~ 230VAC/2A, 50Hz/60Hz |
| Weight |
17.64 lbs |
| Dimensions |
43cm x 37cm x 9.6cm |
|
| Compression |
H.264 DSP Hardware Compression |
| Resolution |
704 x 480 |
| Frame Rate |
Live 480fps/ Recording 240fps |
| Compression Ratio |
Dynamic 40:1~240:1, Average 40:1~2400:1 |
| Recording Quality |
10 Levels |
| Audio Recording |
24Kbps DPCM Same Speed with Video Stream |
| Live Audio |
Live Audio Monitor Support |
| Display Division |
Full Screen/ Quad/ 8-CH/ Auto Sequence |
| Network |
TCP/IP, Dynamic IP, PPPoE, IE Browser Support |
| Triplex |
Recording/ Playback/ Network Access |
| Alarm Function |
Sensor Input/ Video Loss/ Motion Detection |
| Alert Alarm |
Sound Alert/ Relay Output |
| Alarm Log |
Record the Alarm Activated Time and Alarm Source,
and Play the Images by Alarm Log Directly |
| Alarm Recording |
Alarm Activates Record Function
Pre-alarm Function Support |
| Program Recording |
4 Sets Program Recording
Enable/ Disable of Recording Can Be Set Daily
Each Program is Based on a Specific Set Time in a Week |
| Playback (Search) Mode |
Playback Directly by Selected Time
Can Be Searched by Saved Time Log
Can Be Searched by Alarm Log |
| Playback Mode |
Fast Forward x2 x4 x6 x8
Slow Speed Forward /2 /4 /6 /8
Single Frame Playback
Forward Skip Playback/Reverse Skip Playback |
| Playback Display |
Full Screen Display & Quad Display |
| Backup File Playback Function |
USB Disk Can Read Files from PC
Playback Using DVD Player |
¡EH.264 Super Compression
