| Video Type |
NTSC |
PAL |
| Video Input |
16 CH Input / 1V p-p / 75 Ohm / BNC |
| Audio Input |
4 CH Input / RCA |
| Video Output |
16 CH Looping Output/ BNC, 1 CH Monitor Output/ BNC,
1 CH SPOT Output/ BNC, 1 CH VGA Output (800x600, 60Hz) |
| Display Mode |
Full Mode, 3(PIP)/4/9/16 Division, Circulate Auto Switcher, Digitize Zoom for Full Mode |
| Display Resolution |
720 x 480 |
720 x 576 |
| Recording Resolution |
Highest |
720 x 480 |
Highest |
720 x 576 |
High |
720 x 240 |
High |
720 x 288 |
Normal |
352 x 240 |
Normal |
352 x 288 |
| Data Size |
Normal Image |
13~17KB |
Normal Image |
15~19KB |
Complex Image |
23~28KB |
Complex Image |
25~30KB |
| Recording Speed |
Highest |
Max 30 fps |
Highest |
Max 25 fps |
High |
Max 60 fps |
High |
Max 50 fps |
Normal |
Max 120 fps |
Normal |
Max 100 fps |
| Compression Algorithm |
MPEG4 based (none-standard) |
| OS |
Embedded Linux |
| Triplex |
Record / Playback / Network |
| Recording Mode |
Full-time, Manual, Schedule, Event (Pre-Recording) |
| Schedule Recording |
Every day circulation, four sector (full-time/ minute) |
| Status Indicator (LED) |
Power, Record, Playback, Network, USB Archive |
| Event Mode |
Alarm Trigger, Motion Trigger
Recording Duration: off, 1~99 Sec. |
| Alarm Connect |
16 Alarm In / 1 Relay Out (N.O. or N.C. selectable) |
| Playback |
Normal: x1 multiple speed
Fast Forward: x2 / x4 / x6 multiple speed
Rewind: x2 / x4 / x6 multiple speed
Move 1 image per pushbutton at still image (STILL Controller)
Searching function: Move to search list, Time/ Event/ Manual/ Schedule |
| Network Protocol |
TCP/IP (Static IP, DHCP) / RJ45 (10M/100M) |
| Communication Protocol |
RS-485 |
| HDD Type |
Internal IDE / ATA-66 / 3.5 inch / 7200 rpm x2; SATA HDD x2 (Optional) |
| HDD Management |
Pre-formatting not required (Automatic formatting by system) |
| P/T/Z Control |
Internal Communication Protocol (PELCO P, PELCO D, MIKAMI)
RS-485 interface Control |
| Archiving |
USB 2.0 (Including USB 1.1), CD-RW (DVD-RW Optional) |
| Firmware Update |
Use mix with USB 2.0 to arrive at USB flash drive firmware update |
| Multi-language |
English / Traditional Chinese / Simplified Chinese / Other (Optional) |
| Control Mode |
Front panel / IR remote-controlled / USB Mouse / LAN |
| Network Control |
Net Viewer (PC application program) to LAN download |
| Network Function |
Live Play Viewer / Network event list Play Back / USB flash drive File Play / PTZ Control |
| Power Supply |
AC115V/ AC230V 150W MAX. 50~60Hz |
| Dimensions |
43(W) x 37(D) x 9.6(H) cm (standard 2U machine) |
| Weight |
8kg (Without Hard Disk) |
| Operating Temperature |
-5oC ~ 45oC |
ˇEMPEG-4 Compress Format
